Homag Ambition 2270

Machine Information Sheet

Inventory # 4875
Machine Type Edgebanders
Manufacturer Homag
Model Ambition 2270
Year 2011
Region PA
Voltage 480/3/60

Can be tranformed to required voltage for a nominal fee. Single phase available thru a phase converter

Condition Good
Machine Capacities •Two(2) Coil Edgebanding Magazine •Pressure zone with one (1) driven roller and six (6) secondary pressure rollers •Snipping straight and chamfer unit with two (2) motors, 0.8kW, 12,000 RPM •Top and bottom flush trimming unit with two (2) motors inline (above and below), 1.5kW, 12,000 RPM •Profile trimming unit for crosswise processing of postforming or softforming parts and for rounding plastic edges to panel front and rear edge on top and bottom •Scraping device for tracing top, bottom and laterally and for rounding-off pre-trimmed PVC edges •Finish unit top and bottom for longitudinal edges •Power Controll PC 22 with PLC control •Servo control of infeed fence •Hand-held remote control offers 1) setup mode, 2) feed start/stop, 3) emergency stop functions •Feed Chain Height: ~37-7/32" (950mm) •Min. Work Piece Thickness: 15/32" (12mm) •Max. Work Piece Thickness: 2-3/8" (60mm) •Edge Thickness, Strips: 0.16" to 25/32" (0.4mm to 20mm) •Edge Thickness, Coils: 0.12" to 1/8" (0.3mm to 3mm) •Variable Feed Speed: 59 ft/min to 82 ft/min (18 m/min to 25 m/min) •Dust Extraction: 3678 CFM, 9.84"/ws •Air Requirement: 100 PSI (7 bar)
Sales Price $-
Reduced No
Approximate Monthly Lease $0.00USD

Approximate monthly payments are based on approximate lending rate considering 1st and last month down payment, 60 month term and $1.00 residual buy back. This approximate monthly amount is for budgetary purpose only. Based on US leasing rates.

Aldan Woodworking Machinery Inc. sells pre-owned/used machinery on a first come, first served basis. Pre-owned/used machinery is not covered under any warranty or Government requirements. It is purchased "as-is - where-is, with all faults." Descriptions and specifications are to the best of our knowledge (some information is communicated via third party sources). It is strongly recommended that the machinery be inspected prior to purchasing to confirm the condition and specification. Additional charges such as crating and loading may apply.
