Houfek Bulldog 5-2M-1100-RC Houfek Bulldog 5-2M-1100-RC
Machine Information Sheet
| Inventory # | 5384 |
| Machine Type | Sanders - Planer/Wide Belt |
| Manufacturer | Houfek Bulldog 5-2M-1100-RC |
| Model | Houfek Bulldog 5-2M-1100-RC |
| Year | 2014 |
| Region | |
| Voltage | 230/3/60
Can be tranformed to required voltage for a nominal fee. Single phase available thru a phase converter |
| Condition | Very Good |
| Machine Capacities | Frame is welded out of mild steel profiles with 5 ? 6 mm side width. Flanged drive motors for drive of working units are hung at the bottom of frame. Hanging of motors is managed in vertical slots of support frame plates. Control Panel ? Right Front 2 Amperage meters Feed speed control Digital setting for table Joy stick for table rise/fall Start/Stop buttons for sanding heads Control Panel ? Left Side Control switch for pneumatic rise/lower front contact roll Pressure control for oscillation control of sanding belts 1st sanding unit ? Steel Grooved Roll @ 160mm dia. 2nd sanding unit combination ? Rubber roll @ 45? Sh @ 160mm dia. + Polish pad 50mm wide Motorized work table height adjustment Star-Delta switch 1st roll pneumatically lifting from control panel 2nd roll pneumatically lifting from control panel Mechanically adjustable polish pad INFRA sensor for sanding belt centering LED display for table position Workpiece thickness measuring ? positioner Rubber pressure rolls @ 55mm diameter Electromagnetic pneumatic disc motor brake CSA components Provincial electrically inspected |
| Sales Price | 0 |
| Reduced | No |
| Approximate Monthly Lease | $0.00No
Approximate monthly payments are based on approximate lending rate considering 1st and last month down payment, 60 month term and $1.00 residual buy back. This approximate monthly amount is for budgetary purpose only. Based on US leasing rates. |
Aldan Woodworking Machinery Inc. sells pre-owned/used machinery on a first come, first served basis. Pre-owned/used machinery is not covered under any warranty or Government requirements. It is purchased "as-is - where-is, with all faults." Descriptions and specifications are to the best of our knowledge (some information is communicated via third party sources). It is strongly recommended that the machinery be inspected prior to purchasing to confirm the condition and specification. Additional charges such as crating and loading may apply.
