Homag Vantech 510 BHP008 Vantech optimat 510



Machine Information Sheet

Inventory # 5186
Machine Type CNC Routers - Flat Table, Nesting
Manufacturer Homag Vantech 510
Model BHP008 Vantech optimat 510
Year 2015
Region
Voltage //

Can be tranformed to required voltage for a nominal fee. Single phase available thru a phase converter

Condition Very Good
Machine Capacities All specs are accurate to the best of our knowledge. Interested buyers should confirm all details before purchasing. Specs: 5 x 10 nesting flat table Z axis is 9.6 inches Max material thickness is: 3.9 inches. Speed: "X" Axis is 236 FPM (72 MPM), "Y" axis is 203 FPM (62 MPM), "Z" axis 82 FPM (25 MPM); The head travels via AC brushless drives & THK linear motion guides on all axes. Worktable: User-Friendly "S/C Tech MATRIX" grooved phenolic vacuum table for easy vacuum pod placement; (3) Pneumatic locator/positioning pins in "X" axis & (1) pneumatic locator/positioning pins in "Y" axis. (4) Table vacuum work zones, can be used independently or together for full table area Foot pedal vacuum zone controls. Machining: (1) 12 HP (9 kW) High speed electro-spindle router with "HSK F 63" adaptor; constant duty, variable speed from 1,250
- 24,000 RPM, RH or LH rotation. (1) 9-Position ATC rack located at the end of machine. Boring unit with 2 HP (1.5 kW) motor & (7) Independent vertical spindles with "Quick Change" drill bit holders; programmable variable speed from 1,500
- 7,500 RPM; Touch-off tool length measuring device. Machine & Operator Control: PC Front-End with WEEKE "PC 85T" + Windows "XP" + WoodWOP operating system. 17" TFT Color graphic monitor, keyboard for data entry, PC 85T hand control pendant; CD R/W & floppy drives, EtherNET interface for LAN connection to office PC, RS-232 serial interface, USB ports. "BECKHOFF" Programmable logic control for (3/4) axes, linear, circular & helical interpolation; the controller is contained in a separate free-standing, dust-free control cabinet that can be placed at either the LH or RH side of the machine. Complete with: (4) 100 m³/Hr Vacuum pumps; light curtain (machine will stop if operator enters work area), safety fencing, separate control cabinet.
Sales Price 0
Reduced No
Approximate Monthly Lease $0.00CDN

Approximate monthly payments are based on approximate lending rate considering 1st and last month down payment, 60 month term and $1.00 residual buy back. This approximate monthly amount is for budgetary purpose only. Based on US leasing rates.

Aldan Woodworking Machinery Inc. sells pre-owned/used machinery on a first come, first served basis. Pre-owned/used machinery is not covered under any warranty or Government requirements. It is purchased "as-is - where-is, with all faults." Descriptions and specifications are to the best of our knowledge (some information is communicated via third party sources). It is strongly recommended that the machinery be inspected prior to purchasing to confirm the condition and specification. Additional charges such as crating and loading may apply.
