Marinus Promax
Machine Information Sheet
| Inventory # | 5354 |
| Machine Type | End Profilers |
| Manufacturer | Marinus |
| Model | Promax |
| Year | 2010 |
| Region | QU |
| Voltage | 600/3/60
Can be tranformed to required voltage for a nominal fee. Single phase available thru a phase converter |
| Condition | Good |
| Machine Capacities | The exceptional feature of this finished profiling machine for the production of parquet is that the length cutting, fault triggering and frontal profiling are carried out in one pass. The machine is equipped for this with two removal saw aggregates and a two-spindle profiling aggregate. The workpiece is advanced by means of toothed chains and pressure rollers acting from above. Functioning The initial material is already profiled parquet strips. Before the entry, the defective points are marked on the workpiece by the operator with two chalk lines and placed back on the entry roller. A chalk line scanner inside the machine recognizes the chalk lines and causes the removal of the defective points on the machine control . Then the two-spindle milling unit performs the finished profiling at the end of the separated parquet and at the front side of the rest of the workpiece. After the milling process is finished, the workpiece advances to the next chalk line and the cycle starts again. Fixed lengths can optionally be cut off instead of defective points. From the simultaneous machining of the front and rear edges as well as the short touch time, this results in short processing times per workpiece. Use Finished profiling of wall and floor panels Technical data Part length: 450 mm up to 6,000 mm Part width: 50 mm up to 300 mm Piece thickness: 8 up to 30 mm Capacity: 24 pieces every minute Also available with the machine a motorized infeed system (from molder outlet to Marinus inlet) add $25,000.00CDN value of $75,000.00 CDN |
| Sales Price | 0 |
| Reduced | |
| Approximate Monthly Lease | $0.00
Approximate monthly payments are based on approximate lending rate considering 1st and last month down payment, 60 month term and $1.00 residual buy back. This approximate monthly amount is for budgetary purpose only. Based on US leasing rates. |
Aldan Woodworking Machinery Inc. sells pre-owned/used machinery on a first come, first served basis. Pre-owned/used machinery is not covered under any warranty or Government requirements. It is purchased "as-is - where-is, with all faults." Descriptions and specifications are to the best of our knowledge (some information is communicated via third party sources). It is strongly recommended that the machinery be inspected prior to purchasing to confirm the condition and specification. Additional charges such as crating and loading may apply.
